Category |
Integrated Circuits (ICs)
Linear
Amplifiers
Instrumentation, Op Amps, Buffer Amps
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
LinCMOS™ |
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Amplifier Type |
Standard (General Purpose) |
|
|
Number of Circuits |
4
|
|
|
Output Type |
-
|
|
|
Slew Rate |
-
|
|
|
Gain Bandwidth Product |
1 MHz
|
|
|
Current - Input Bias |
45 nA
|
|
|
Voltage - Input Offset |
2 mV
|
|
|
Current - Supply |
1.5mA
|
|
|
Current - Output / Channel |
40 mA
|
|
|
Voltage - Supply Span (Min) |
3 V
|
|
|
Voltage - Supply Span (Max) |
32 V
|
|
|
Operating Temperature |
0°C ~ 70°C (TJ)
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
14-DIP (0.300", 7.62mm)
|
|
|
Supplier Device Package |
14-PDIP
|
|
|
Base Product Number |
LM324 |
