HMLB25201B-R47MSR
Part Number:
HMLB25201B-R47MSR
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
CCEA Technical Lighting
Description:
FIXED IND 470NH 4.5A 26MOHM SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Delta Electronics/Cyntec |
|
|
Series |
HMLB25201B |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Obsolete
|
|
|
Type |
-
|
|
|
Material - Core |
Metal |
|
|
Inductance |
470 nH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
4.5 A |
|
|
Current - Saturation (Isat) |
4.55A
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
26mOhm Max
|
|
|
Q @ Freq |
-
|
|
|
Frequency - Self Resonant |
-
|
|
|
Ratings |
-
|
|
|
Operating Temperature |
-55°C ~ 125°C
|
|
|
Inductance Frequency - Test |
1 MHz
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
1008 (2520 Metric)
|
|
|
Supplier Device Package |
1008
|
|
|
Size / Dimension |
0.098" L x 0.079" W (2.50mm x 2.00mm)
|
|
|
Height - Seated (Max) |
0.047" (1.20mm)
|
|
|
Base Product Number |
HMLB25201 |
