EEU-FR1V681
Part Number:
EEU-FR1V681
Product Classification:
LED Drivers
Manufacturer:
Alliance Magnets
Description:
CAP ALUM 680UF 20% 35V RADIAL TH
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Capacitors
Aluminum Electrolytic Capacitors
|
|
|
Mfr |
Panasonic Electronic Components |
|
|
Series |
FR-A |
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
Capacitance |
680 µF |
|
|
Tolerance |
±20%
|
|
|
Voltage - Rated |
35 V
|
|
|
ESR (Equivalent Series Resistance) |
-
|
|
|
Lifetime @ Temp. |
10000 Hrs @ 105°C
|
|
|
Operating Temperature |
-40°C ~ 105°C
|
|
|
Polarization |
Polar
|
|
|
Ratings |
-
|
|
|
Applications |
General Purpose |
|
|
Ripple Current @ Low Frequency |
1.635 A @ 120 Hz
|
|
|
Ripple Current @ High Frequency |
2.18 A @ 100 kHz
|
|
|
Impedance |
20 mOhms
|
|
|
Lead Spacing |
0.197" (5.00mm)
|
|
|
Size / Dimension |
0.394" Dia (10.00mm)
|
|
|
Height - Seated (Max) |
0.866" (22.00mm)
|
|
|
Surface Mount Land Size |
-
|
|
|
Mounting Type |
Through Hole |
|
|
Package / Case |
Radial, Can
|
|
|
Base Product Number |
EEU-FR |
