CMF-RL10-0
Part Number:
CMF-RL10-0
Product Classification:
Fan Accessories
Manufacturer:
Almit (ANA TRADING)
Description:
PTC RESET FUSE 220V 150MA RADIAL
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Circuit Protection
PTC Resettable Fuses
|
|
|
Manufacturer |
Bourns Inc.
|
|
|
Series |
CMF-RL |
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
Type |
Ceramic
|
|
|
Voltage - Max |
220V (600V Int)
|
|
|
Current - Hold (Ih) (Max) |
150 mA
|
|
|
Current - Trip (It) |
300 mA
|
|
|
Current - Max |
3 A
|
|
|
Time to Trip |
450 ms
|
|
|
Resistance - 25°C (Typ) |
10 Ohms
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
Radial, Disc
|
|
|
Size / Dimension |
0.374" L x 0.177" W (9.50mm x 4.50mm)
|
|
|
Height - Seated (Max) |
0.532" (13.50mm)
|
|
|
Thickness (Max) |
-
|
|
|
Lead Spacing |
0.197" (5.00mm)
|
|
|
Approval Agency |
UR
|
|
|
Base Product Number |
CMF-RL |
