BAT46WQ-7-F
Part Number:
BAT46WQ-7-F
Product Classification:
Toggle Switches
Manufacturer:
Accuenergy
Description:
DIODE SCHOTTKY 100V 150MA SOD123
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Discrete Semiconductor Products
Diodes
Rectifiers
Single Diodes
|
|
|
Mfr |
Diodes Incorporated |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Technology |
Schottky |
|
|
Voltage - DC Reverse (Vr) (Max) |
100 V
|
|
|
Current - Average Rectified (Io) |
150mA
|
|
|
Voltage - Forward (Vf) (Max) @ If |
450 mV @ 10 mA
|
|
|
Speed |
Small Signal =< 200mA (Io), Any Speed
|
|
|
Current - Reverse Leakage @ Vr |
2 µA @ 75 V
|
|
|
Capacitance @ Vr, F |
12pF @ 1V, 1MHz
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount |
|
|
Package / Case |
SOD-123 |
|
|
Supplier Device Package |
SOD-123
|
|
|
Operating Temperature - Junction |
-55°C ~ 125°C
|
|
|
Base Product Number |
BAT46 |
