ADP7142AUJZ-5.0-R7
Part Number:
ADP7142AUJZ-5.0-R7
Product Classification:
Keylock Switches
Manufacturer:
AEM Central Semiconductor
Description:
IC REG LINEAR 5V 200MA TSOT-23-5
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Fixed |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
40V
|
|
|
Voltage - Output (Min/Fixed) |
5V
|
|
|
Voltage - Output (Max) |
-
|
|
|
Voltage Dropout (Max) |
0.42V @ 200mA
|
|
|
Current - Output |
200mA |
|
|
Current - Quiescent (Iq) |
140 µA
|
|
|
Current - Supply (Max) |
320 µA
|
|
|
PSRR |
88dB ~ 50dB (10kHz ~ 1MHz)
|
|
|
Control Features |
Enable
|
|
|
Protection Features |
Over Temperature, Short Circuit
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
SOT-23-5 Thin, TSOT-23-5
|
|
|
Supplier Device Package |
TSOT-23-5
|
|
|
Base Product Number |
ADP7142 |
