ABM3B-8.000MHZ-10-1-U-T
Part Number:
ABM3B-8.000MHZ-10-1-U-T
Product Classification:
AC DC Configurable Power Supply Modules
Manufacturer:
Agile MwT
Description:
CRYSTAL 8.0000MHZ 10PF SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Crystals, Oscillators, Resonators
Crystals
|
|
|
Mfr |
Abracon LLC |
|
|
Series |
ABM3B |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
MHz Crystal
|
|
|
Frequency |
8 MHz
|
|
|
Frequency Stability |
±10ppm
|
|
|
Frequency Tolerance |
±10ppm
|
|
|
Load Capacitance |
10pF
|
|
|
ESR (Equivalent Series Resistance) |
200 Ohms
|
|
|
Operating Mode |
Fundamental
|
|
|
Operating Temperature |
-10°C ~ 60°C
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
4-SMD, No Lead |
|
|
Size / Dimension |
0.197" L x 0.126" W (5.00mm x 3.20mm)
|
|
|
Height - Seated (Max) |
0.043" (1.10mm)
|
