80SQ045NRLG
Part Number:
80SQ045NRLG
Product Classification:
Toggle Switches
Manufacturer:
ADDA USA
Description:
DIODE SCHOTTKY 45V 8A AXIAL
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Discrete Semiconductor Products
Diodes
Rectifiers
Single Diodes
|
|
|
Mfr |
onsemi |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
|
|
|
Part Status |
Active
|
|
|
Technology |
Schottky |
|
|
Voltage - DC Reverse (Vr) (Max) |
45 V
|
|
|
Current - Average Rectified (Io) |
8A
|
|
|
Voltage - Forward (Vf) (Max) @ If |
550 mV @ 8 A
|
|
|
Speed |
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Current - Reverse Leakage @ Vr |
1 mA @ 45 V
|
|
|
Capacitance @ Vr, F |
-
|
|
|
Mounting Type |
Through Hole |
|
|
Package / Case |
DO-201AA, DO-27, Axial |
|
|
Supplier Device Package |
Axial
|
|
|
Operating Temperature - Junction |
-65°C ~ 125°C
|
|
|
Base Product Number |
80SQ045 |
