5-104362-2
Part Number:
5-104362-2
Product Classification:
Excavators, Hooks, Picks, Probes, Tuning Tools
Manufacturer:
Cinch Connectivity Solutions
Description:
CONN HEADER VERT 3POS 2.54MM
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Connectors, Interconnects
Rectangular Connectors
Headers, Male Pins
|
|
|
Mfr |
TE Connectivity AMP Connectors |
|
|
Series |
AMPMODU MTE |
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Connector Type |
Header |
|
|
Contact Type |
Male Pin
|
|
|
Pitch - Mating |
0.100" (2.54mm) |
|
|
Number of Positions |
3 |
|
|
Number of Rows |
1
|
|
|
Row Spacing - Mating |
-
|
|
|
Number of Positions Loaded |
All
|
|
|
Style |
Board to Board or Cable |
|
|
Shrouding |
Shrouded - 4 Wall
|
|
|
Mounting Type |
Through Hole |
|
|
Termination |
Press-Fit, Solder
|
|
|
Fastening Type |
Latch Holder
|
|
|
Contact Length - Mating |
0.230" (5.84mm)
|
|
|
Contact Length - Post |
0.130" (3.30mm)
|
|
|
Overall Contact Length |
0.550" (13.97mm)
|
|
|
Insulation Height |
0.535" (13.60mm)
|
|
|
Contact Shape |
Square
|
|
|
Contact Finish - Mating |
Gold
|
|
|
Contact Finish Thickness - Mating |
15.0µin (0.38µm)
|
|
|
Contact Finish - Post |
Tin
|
|
|
Contact Material |
Brass
|
|
|
Insulation Material |
Thermoplastic
|
|
|
Features |
Keying Slot
|
|
|
Operating Temperature |
-65°C ~ 105°C
|
|
|
Ingress Protection |
-
|
|
|
Material Flammability Rating |
UL94 V-0
|
|
|
Insulation Color |
Black
|
|
|
Current Rating (Amps) |
3A
|
|
|
Voltage Rating |
267V
|
|
|
Mated Stacking Heights |
-
|
|
|
Contact Finish Thickness - Post |
100.0µin (2.54µm)
|
|
|
Applications |
Automotive, General Purpose, Medical, Telecommunications
|
|
|
Base Product Number |
104362 |
