2060-452/998-404
Part Number:
2060-452/998-404
Product Classification:
LED Lighting Kits
Manufacturer:
ATC - Diversified Electronics
Description:
2 Position Wire to Board Terminal Block Horizontal with Board 0.157" (4.00mm) Surface Mount
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
| Manufacturer | WAGO Corporation |
| Series | 2060 |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Number of Levels | 1 |
| Positions Per Level | 2 |
| Pitch | 0.157" (4.00mm) |
| Mating Orientation | Horizontal with Board |
| Current | 9:00 AM |
| Voltage | 320 V |
| Wire Gauge | 18-24 AWG |
| Mounting Type | Surface Mount |
| Wire Termination | Screwless - Push Button Clamp |
| Features | - |
| Color | White |
| Operating Temperature | -60°C ~ 105°C |
| Housing Material | Polyphthalamide (PPA), Glass Filled |
| Contact Material - Plating | Copper Alloy - Tin Plated |
| Clamp Material - Plating | Copper Alloy |
| Screw Material - Plating | - |
| Torque - Screw | - |
| Screw Thread | - |
