0630CDMCCDS-4R7MC
Part Number:
0630CDMCCDS-4R7MC
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
APG
Description:
4.7 µH Shielded Molded Inductor 6.3 A 33mOhm Max Nonstandard
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
| Mfr | Sumida America Components Inc. |
| Series | 0630CDMC/DS |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Type | Molded |
| Material - Core | Metal |
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 6.3 A |
| Current - Saturation (Isat) | 6.8A |
| Shielding | Shielded |
| DC Resistance (DCR) | 33mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | SMD |
| Size / Dimension | 0.276" L x 0.260" W (7.00mm x 6.60mm) |
| Height - Seated (Max) | 0.118" (3.00mm) |
